7.5KN-90KN Electric Chain Hoist Aluminium Alloy Electric Chain Fall
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Name: | Aluminium Alloy Chain Type Handle Hoist | Item No.: | 14401-14445 |
|---|---|---|---|
| Rated Load: | 7.5-90KN | Minimum Distance Between Hooks: | 320-700mm |
| Standard Lifting Height: | 1.5m | Number Of Lines Of Lifting Chain: | 1/2/3 Row |
| Weight: | 4.7-24KG | Weight Of 1m Chain: | 0.55-3.2KG |
| Warranty: | 1 Year | ||
| Highlight: | 90KN Electric Chain Hoist,7.5KN Electric Chain Hoist,Aluminium Alloy Electric Chain Fall |
||
7.5KN-90KN Electric Chain Hoist Aluminium Alloy Electric Chain Fall
Aluminium Alloy Chain Type Handle Hoist Good Quality Manual Handle Series Lifting Electric Chain Hoist
Suntech Power Tools, located in southeast China, is the earliest origin Power Tools Leading City in China. We manufacture various cable pulling tools, hydraulic tension and puller to support transmission work. All products are produced per ISO 9001:2008 and sold to over 50 countries worldwide, earning excellent brand reputation. Customization is available for items like stringing blocks, cable rollers, cable jack stands, etc. Construction Safety Tools have no MOQ requirements.
Features
- Lightweight design for simple manual operation
- Strong safety performance and high reliability
- 360° rotating hand chain guide for operation from all angles
- Allows operator to stay away from danger zones
- Specifically designed for heavy industry applications
Applications
Suitable for lifting machine parts, tightening steel stranded wire and aluminum stranded wire in construction applications.
Specifications
| Item No. | 14401 | 14411 | 14421 | 14431 | 14231 | 14441 |
|---|---|---|---|---|---|---|
| Rated Load(KN) | 7.5 | 15 | 30 | 40 | 60 | 90 |
| Minimum distance between hooks(MM) | 320 | 380 | 480 | 380 | 620 | 700 |
| Standard lifting height(M) | 1.5 | |||||
| Number of lines of lifting chain(row) | 1 | 1 | 1 | 1 | 2 | 3 |
| Net weight(KG) | 4.7 | 5.8 | 9.5 | 14.5 | 18 | 24 |
| Item No. | Length of chain(3M) | 14402 | 14412 | 14422 | 14432 | 14442 | 14446 |
|---|---|---|---|---|---|---|---|
| Length of chain(5M) | 14404 | 14414 | 14424 | 14434 | 14444 | 14448 | |
| Encasement dimension(MM) | 0.55 | 1.1 | 1.7 | 2.1 | 2.8 | 3.2 |
