30KN-160KN Ground Anchor For Transmission Tower Foundation
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Name: | Ground Anchor | Item No.: | 02120-02123 |
|---|---|---|---|
| Model: | SDM3-SDM16 | Allpwable Pull: | 30-160KN |
| Valid Depth: | 1.8-2.5M | Weight: | 22.5-105KG |
| Highlight: | 160KN Ground Anchor,30KN Ground Anchor,Transmission Tower Foundation Ground Anchor |
||
30KN-160KN Ground Anchor For Transmission Tower Foundation
Professional Ground Anchor For Transmission Tower Foundation And Guy Wire Systems
Essential foundation component for power transmission and distribution systems providing critical structural stability for towers, poles, and equipment. These ground anchors are engineered to create secure underground attachment points for guy wires and support systems, ensuring structural integrity under various environmental conditions.
Key Features
- Superior Holding Power: Excellent grip in various soil conditions with consistent performance under tension loads and reliable anchoring in different terrains.
- Robust Construction: High-strength steel materials with corrosion-resistant coatings and durable welding for impact-resistant design.
- Corrosion Protection: Hot-dip galvanized coating with weather-resistant finish and UV protection layer for long-lasting surface protection.
- Installation Efficiency: Easy installation process with minimal site preparation required and quick deployment capability.
- Safety Assurance: High safety factor design with secure connection points and load capacity indicators.
Typical Applications
- Transmission tower foundation anchoring
- Utility pole guying systems
- Substation equipment anchoring
- Temporary power structure stabilization
- Renewable energy project foundations
- Emergency restoration operations
- Communication tower anchoring
- Wind turbine guy wire systems
Workflow Integration
- Compatible with standard guy wire systems
- Works with various foundation types
- Integrates with existing infrastructure
- Adaptable to different soil conditions
- Suitable for multiple installation methods
Maintenance Benefits
- Corrosion-resistant materials reduce maintenance
- Long service life minimizes replacements
- Easy inspection access
- Minimal upkeep requirements
- Reliable performance over time
Installation Guidelines
Site Assessment
- Soil condition evaluation
- Load requirement calculation
- Installation depth determination
- Safety zone establishment
Installation Process
- Proper positioning and alignment
- Correct depth achievement
- Secure connection establishment
- Initial tension application
Final Verification
- Load capacity testing
- Connection security check
- Environmental protection verification
- Documentation completion
Industry Compliance
- Meets utility industry standards
- Complies with structural safety codes
- Certified by quality control agencies
- Approved by engineering organizations
Why Professionals Choose Us
- 40% higher load capacity than standard anchors
- 35% faster installation time
- 50% better corrosion resistance
- 5-year performance warranty
- 24/7 technical support
Technical Specifications
| Item number | Model | Allowable pull(KN) | Valid depth(m) | Main size(mm) | Weight(kg) |
|---|---|---|---|---|---|
| 02120 | SDM3 | 30 | 1.8 | 800 × 250 × 150 Φ25 | 22.5 |
| 02121 | SDM5 | 50 | 1.8 | 900 × 270 × 180 Φ28 | 30 |
| 02122 | SDM10 | 100 | 2.0 | 1200 × 290 × 220 Φ36 | 55 |
| 02123 | SDM16 | 160 | 2.5 | 1500 × 500 × 258 | 105 |
Customer Support
- Free engineering consultation
- Installation guidance provided
- Maintenance training programs
- Emergency support services
- Regular quality inspections
Purchasing Options
- Standard sizes available
- Custom designs offered
- Bulk order discounts
- Express delivery service
- Complete installation packages
Environmental Advantages
- Recyclable materials used
- Sustainable manufacturing
- Low environmental impact
- Eco-friendly packaging
- Long product lifecycle
Safety Features
- High tensile strength
- Secure locking mechanisms
- Load capacity labels
- Earthquake resistance
- Weather endurance
Technical Services
- Custom design services
- Engineering calculations
- Installation supervision
- Maintenance contracts
- System upgrades
