30KG - 150KG 660 Series Large Diameter Rope Pulley Stringing Block Mc Nylon Sheave
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Sheave: | 1/3/5 | Rated Load: | 20-60KN |
|---|---|---|---|
| Weight: | 30-150KG | SHeave Features: | MC Nylon Sheave |
| Highlight: | 30KG Large Diameter Rope Pulley,660 Series Large Diameter Rope Pulley,150KG Nylon Sheave |
||
30KG - 150KG 660 Series Large Diameter Rope Pulley Stringing Block Mc Nylon Sheave
660 Series Stringing Block Mc Nylon Sheave
About Suntech Power Tools: Located in southeast China, the earliest origin of Power Tools Leading City in China. We manufacture various cable pulling tools, hydraulic tensioners and pullers for transmission work. All products are produced per ISO 9001:2008 and sold to over 50 countries worldwide, earning excellent brand reputation. We accept OEM orders and can customize items like stringing blocks, cable rollers, cable jack stands, etc. Construction Safety Tools have no minimum order quantity requirements.
Product Specifications
| Item Number | Model | Number of Sheaves | Rated Load (kN) | Weight (kg) | Features |
|---|---|---|---|---|---|
| 10121 | SHD660 | 1 | 20 | 30 | Rubber lined aluminium sheave |
| 10122 | SHS660 | 3 | 40 | 100 | Middle: Cast steel sheave Conductor: Rubber lined aluminium sheave |
| 10123 | SHW660 | 5 | 60 | 150 | Middle: Cast steel sheave Conductor: Rubber lined aluminium sheave |
| 10124 | SHDN660 | 1 | 20 | 26 | MC nylon sheave |
| 10125 | SHSN660 | 3 | 40 | 86 | Middle: MC nylon sheave Conductor: Rubber lined aluminium sheave |
| 10126 | SHWLN660 | 5 | 60 | 120 | Middle: MC nylon sheave Conductor: Rubber lined aluminium sheave |
| 10127 | SHSQN660 | 3 | 40 | 70 | MC nylon sheave |
| 10128 | SHWQN660 | 5 | 60 | 110 | MC nylon sheave |
| 10130 | SHQ660A | 7 | 75 | 190 | Middle: cast steel sheave Conductor: MC nylon sheave |
