15HP Walking Tractor Winch Cable Winch Machine For Controlled Load Handling
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Name: | Walking Tractor Winch | Item No.: | 09171-09172 |
|---|---|---|---|
| Model: | 12-A | Power: | 15HP |
| Weight: | 550-600KG | Warranty: | 1 Year |
| Highlight: | 15HP Walking Tractor Winch,15HP Cable Winch Machine,Walking Tractor Cable Winch Machine |
||
15HP Walking Tractor Winch Cable Winch Machine For Controlled Load Handling
Walking Tractor Winch Precision Tool For Controlled Load Handling
Professional Load Handling Performance
- Delivers up to 3 tons of pulling force for agricultural applications
- Smooth operation ensures safe load transportation
- Maintains precise control on slopes and uneven terrain
Agricultural-Grade Construction
- Reinforced steel frame withstands tough field conditions
- High-strength cable drum for extended durability
- Weather-resistant components for outdoor work
Advanced Safety Features
- Automatic braking system prevents uncontrolled movement
- Overload protection mechanism
- Emergency release function
Comprehensive Applications
- Hillside farming operations
- Orchard management
- Forestry wood extraction
- Rural material transportation
- Irrigation equipment handling
Technical Specifications
| Item No. | Model | Ground Clearance (MM) | Wheel-base (MM) | Power (HP) | Speed (RPM) | Travel speed (KM/H) | Outline size (MM) | Weight (KG) |
|---|---|---|---|---|---|---|---|---|
| 09171 | 12-A | 150 | 1040 | 15 | 2000 | 3-13 | 2670*1040*1300 | 550 |
| 09172 | 12-B | 150 | 1040 | 15 | 2000 | 3-13 | 2670*1040*1300 | 600 |
| Gear | Ⅰ | Ⅱ | Ⅲ | 4 | Reversal Ⅰ | Reversal Ⅱ |
|---|---|---|---|---|---|---|
| Traction force (T) | 60 | 37 | 20 | 12 | / | / |
| Traction speed (M/MIN) | 11.7 | 18.9 | 34.4 | 55.6 | 6.2 | 21.3 |
Additional Features
- Ergonomic Design: Lightweight and compact for easy tractor mounting
- Low Maintenance: Self-lubricating bearings and easy-access grease points
- Productivity: 40% faster than manual methods with fast operation cycle
- Quality Assurance: 2-year warranty with factory tested units
- Power Options: Available in PTO, hydraulic, and electric motor versions
