16.6KN-296KN Dynema Rope Pilot Wire 13G/M - 247.3G/M Braided Nylon Rope

16.6KN-296KN Dynema Rope Pilot Wire 13G/M - 247.3G/M Braided Nylon Rope
16.6KN-296KN Dynema Rope Pilot Wire 13G/M - 247.3G/M Braided Nylon Rope 16.6KN-296KN Dynema Rope Pilot Wire 13G/M - 247.3G/M Braided Nylon Rope 16.6KN-296KN Dynema Rope Pilot Wire 13G/M - 247.3G/M Braided Nylon Rope 16.6KN-296KN Dynema Rope Pilot Wire 13G/M - 247.3G/M Braided Nylon Rope 16.6KN-296KN Dynema Rope Pilot Wire 13G/M - 247.3G/M Braided Nylon Rope

Large Image :  16.6KN-296KN Dynema Rope Pilot Wire 13G/M - 247.3G/M Braided Nylon Rope Get Best Price

Product Details:
Place of Origin: Ningbo, China
Brand Name: Suntech
Certification: ISO9001
Model Number: Dynema
Payment & Shipping Terms:
Minimum Order Quantity: 1 M
Price: Negotiable
Packaging Details: Wooden Case
Delivery Time: 7-15days
Payment Terms: L/C,T/T
Supply Ability: 10000 M/Month
Contact Now
Detailed Product Description
Name: Dynema Rope Diameter: 4-18mm
Linear Density: 13-247.3G/M Sheath Diameter: 5.5-21mm
Break Force: 16.6-296KN Warranty: 1 Year
Highlight:

296KN Dynema Rope

,

16.6KN Dynema Rope

,

247.3G/M Braided Nylon Rope

16.6KN-296KN Dynema Rope Pilot Wire 13G/M - 247.3G/M Braided Nylon Rope
Product Description
Dynema Rope High Strength Nylon Rope Withstand Voltage Insulation
About Suntech Power Tools: Located in southeast China, the earliest origin of Power Tools Leading City in China. We specialize in various cable pulling tools and hydraulic tension pullers for transmission work. All products are manufactured per ISO 9001:2008 standards and exported to over 50 countries worldwide, earning excellent brand reputation. We accept OEM orders and offer customization for items like stringing blocks, cable rollers, and cable jack stands. No minimum order quantity required for Construction Safety Tools.
Key Features
  • Material: Dinima fiber - the lightest, highest performance fiber available
  • Light weight with high strength (same diameter and strength as steel wire rope but less than 1/7 the weight)
  • Enables more convenient and faster operation
  • Voltage insulation makes it ideal for live operation and crossing applications
Technical Specifications
Diameter (MM) Linear Density (G/M) Sheath Diameter (MM) Linear Density (G/M) Break Force (KN)
4 9.31 5.5 13 16.6
6 20 8 28.2 31.9
8 35 10 48.4 58.8
10 56 12 77 92.5
12 84 14 113.4 137
14 106 16 150 180
16 132 18 177 211
18 186 21 247.3 296
