Hydraulic Underground Cable Puller 20KN-40KN Underground Wire Puller
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Name: | Hydraulic Tension Equipment | Item No.: | 07212-07201 |
|---|---|---|---|
| Weight: | 450-10500KG | Maximum Suitable Conductor Diameter: | 32-48.8mm |
| Number Of Groovr: | 20-40KN | Bottom Of Groovr Diamere: | 1100-1850mm |
| Warranty: | 1 Year | ||
| Highlight: | Hydraulic Underground Cable Puller 20KN,40KN Underground Wire Puller,20KN Underground Wire Puller |
||
Hydraulic Underground Cable Puller 20KN-40KN Underground Wire Puller
Hydraulic Tension Equipment with Infinitely Variable Tension Control
About Suntech Power Tools: Located in southeast China, the earliest origin of Power Tools Leading City in China. We specialize in manufacturing cable pulling tools and hydraulic tension pullers for transmission work. All products are OEM compatible and professionally produced per ISO 9001:2008 standards, exported to over 50 countries worldwide with excellent brand reputation.
We offer customization for items like stringing blocks, cable rollers, cable jack stands, and construction safety tools with no minimum order quantity requirements.
Product Specifications
| Item No. | 07212 | 07155 | 07171 |
|---|---|---|---|
| Model | SA-YZM7.5 | SA-YZ30A | SA-YZ40A |
| Maximum Tension (KN) | 7.5 | 30 | 40 |
| Continuous Tension (KN) | 7.5 | 25 | 35 |
| Maximum Speed (KM/H) | 40m/minute | 5 | 5 |
| Bottom of Groove Diameter (MM) | Φ1100 | Φ1200 | Φ1200 |
| Number of Groove (MM) | / | 5 | 5 |
| Number of Groove (KN) | / | 20 | 40 |
| Maximum Speed Back (KM/H) | / | / | 3 |
| Maximum Suitable Conductor Diameter (MM) | / | Φ32 | Φ32 |
| Engine Power/Speed (KW/RPM) | / | 11/2200 | 51/2500 |
| Dimensions (M) | 2.3*1.2*1.6 | 3.6*1.8*2.4 | 3.4*1.8*2.4 |
| Weight (KG) | 450 | 1700 | 2800 |
